Rift ES24D Frame
$ 699.95
$ 699.95
Description
The Rift ES24D is a high-performance BMX race frame designed for 24" wheels. Made from 7005 double heat-treated alloy, this frame is engineered for serious racers in the Pro and ProXXL categories.
Product Highlights
- Hydro-formed top, down, and chain stays for optimized stiffness and weight
- CNC-machined 3D dropouts with built-in chain tensioners and disc hanger
- Clean, race-ready finish with decals sealed under a clear coat
Specifications
- Type: 7005 double heat-treated aluminum construction
- Axle Length / Size Compatibility: Pro sizes (Pro to ProXXL): Disc brake only
- Material: Hydro-formed top tube, down tube, and chain stays
- Frame Compatibility: CNC chain stay yoke for maximum rear wheel clearance
- Brake Mount: CNC 3D dropouts with integrated tensioners and disc hanger
- Finish Options: Standard or Polished
- 24" Weights: Junior 1270g, Expert 1279g, Pro 1840g, Pro XL 1891g
| 24 Inch Bikes | ||||
|---|---|---|---|---|
| Specs | Junior 24 | Expert 24 | Pro 24 | Pro XL 24 |
| Top Tube Length | 19.3" or 490mm | 20.25" or 515mm | 21.675" or 550mm | 22.25" or 565mm |
| Bottom Bracket Height | 11.0" or 279mm | 11.0" or 279mm | 12.0" or 305mm | 17.75" or 299mm |
| Chainstay Length | 14.175" or 360mm | 14.175" or 360mm | 14.8" or 377mm | 15.4" or 392mm |
| Head Tube Angle | 72° | 72° | 73° | 73° |
| Headset Size (Integrated) | 1-1/8" (1" compatible) | 1-1/8" (1" compatible) | 1-1/8"–1.5" (Tapered) | 1-1/8"–1.5" (Tapered) |
| Seat Tube Angle | 69° | 69° | 70° | 70° |
| Seat Clamp Size | 25.4mm | 25.4mm | 31.8mm | 31.8mm |
| Seat Post Diameter | 22.2mm | 22.2mm | 27.2mm | 27.2mm |
| Frame Weight | 2 lbs 13 oz / 1270g | 2 lbs 14 oz / 1279g | 4 lbs 1 oz / 1840g | 4 lbs 3 oz / 1891g |
